The add-in has tools to assign values to the fire rating property, map line types to each fire rating and generate graphics for plan views.

#AUTODESK REVIT ADDINS FREE#

Revit Properties will let you “Create New Local” from a central file in the same manner that Revit does, however it cannot open a project “Detatched from central” nor can it allow you to choose which worksets to open, or to open the file with auditing turned on.Įven with those limitations, it’s still a very handy free tool! Only versions of Revit that are installed for the same or later version of Revit that last saved the file will be on the list of choices. Revit Properties will show you information about the Revit file, including the version of Revit last used to save the file, and also things like worksharing information.Īs of BIM Project Suite 5.1.8, Revit Properties has been improved to allow actually opening the selected Revit file in a specific version of Revit.

#AUTODESK REVIT ADDINS WINDOWS#

The free Revit Properties tool in CTC’s BIM Project Suite modifies the Windows Explorer / File Explorer interface to quickly provide access to basic data about Revit files by simply right-clicking on them and selecting the “Revit Properties” choice from the Explorer pop-up menu. Instead, it modifies the Windows Explorer / File Explorer interface to provide access to basic data about Revit project files, family files, project template files and family template files, and lets you open those files in the installed version of Revit you choose. Unlike the other tools in BIM Project Suite, Revit Properties does not actually run within Revit.

Return to List Displays Revit File Information.

Remember, only numeric values are allowed for the sequential door numbering. The number entered in the “Start sequence with” textbox will increment by one on selection of each door. Finally, click “Start” button to select the doors from the active document. For sequential door numbering, enter a number in the “Start sequence with” textbox and check the “Auto Swap” checkbox if you want to automatically swap the door number to avoid duplicates. By default, sequential door numbering option is selected. There are two ways to number doors, either utilizing sequential numbering or using “To Room” and “From Room” property of a door. The “Separator” and the “Suffix” fields are optional however, it is required to have a suffix if a separator is defined. The “Suffix” textbox can hold a single letter or a number. The sequence can be alphanumeric but should always end with a number if no suffix is specified. To number rooms, enter a room number in the “Start sequence with” textbox. Add separators and suffices to room and door numbers. Provides a fast and simple way to renumber your rooms and doors.

Current Selection – Only elements in the current selection.

Active View – Only elements from the Active view.

Project – All elements in the active project.

The three options in the “Apply Filter To” dropdown are listed below and determine which elements will be considered in the selection filter. Quick Select has the ability to build a new selection, add to an existing selection, remove items from an existing selection, or replace the current selection altogether.

#AUTODESK REVIT ADDINS HOW TO#

The first step in using Quick Select is to decide how to apply the filter. If additional filtering is needed, Quick Select can be run as many times as needed, each time taking the previous selection and modifying it by either adding or removing elements. It may be desirable to refine a selection with more granularity than can be achieved by a single pass through the Quick Select interface. Search elements that match filter criteria can either be added to, removed from or replace the currently selected items.

Return to List Enables Specific SelectionsĪ Revit add-in that selects elements by filtering specific categories or parameter values.

The user is prompted for each file to be linked which view they want the file to be linked into.

User specifies a basic name and the program will create views incremented from the basic name.

Status text should show the current file that will be linked in.

The user is prompted for each file to specify a new Drafting View name.

The file extension will not be included in the name.

Will automatically name new Drafting Views according to the file name.

Users should be promoted if they want to recursively search subdirectories if they exist.

#AUTODESK REVIT ADDINS SERIES#

The folder method will use a folder and all sub-folders to link in a series of DWG files.This method allows a user to select specific files to link into Revit from a folder location.Automates the process of linking AutoCAD DWG details for use in the Revit project environment.
